Olive Green Cadmium Shell Finish MIL DTL 38999 Series Ⅰ Circular Connector Copper Alloy Contact Material Rugged Durable.High -Current.MS27656T23B44SA

Part Number:MS27656T23B44SA

Product Description:

The MIL-DTL-38999 Series Ⅰ connector, specifically the MS27656T23B44SA model, is a high-performance, rugged connector designed for demanding military and aerospace applications. Known for its exceptional reliability and durability, this connector is part of the MIL-DTL-38999 Series Ⅰ family, which has become a standard in environments that require superior resistance to harsh conditions such as extreme temperatures, vibration, and corrosion.

This particular model, MS27656T23B44SA, features a shell size of 23 and is equipped with four contacts. The contacts are made from a high-quality copper alloy, ensuring excellent electrical conductivity and mechanical strength. Copper alloy contacts are preferred in these connectors due to their ability to maintain stable electrical performance over prolonged use and in challenging environments.

The contact type for this connector is crimp, which provides a secure and reliable electrical connection by mechanically deforming the contact to the wire. Crimp contacts are favored in military and aerospace applications for their superior performance in maintaining low contact resistance and their resistance to vibration-induced loosening. This ensures that the MS27656T23B44SA connector maintains a consistent and dependable electrical connection even in the most demanding conditions.

One of the key features of the MIL-DTL-38999 Series Ⅰ connectors, including the MS27656T23B44SA, is the bayonet coupling mechanism. The bayonet coupling provides a quick and secure method for mating and unmating the connectors, enabling fast assembly and disassembly without compromising the connection’s integrity. This coupling type also ensures that the connector remains firmly locked in place, resisting accidental disconnection during operation.

The electrical performance of the MS27656T23B44SA is impressive, with a current rating of 60 amps per contact. This high current rating makes the connector suitable for power-intensive applications where reliable transmission of electrical power is critical. The combination of four contacts each rated at 60 amps allows the connector to handle substantial electrical loads, making it ideal for use in military vehicles, aircraft, and other high-demand systems.

In addition to its electrical and mechanical attributes, the MIL-DTL-38999 Series Ⅰ connectors are designed to be highly resistant to environmental factors. The shells are constructed to withstand exposure to moisture, dust, and chemical contaminants, ensuring long-term durability and performance. The robust design of the shell size 23 housing provides excellent shielding against electromagnetic interference (EMI), which is vital in sensitive electronic systems.

The MS27656T23B44SA model also complies with the stringent standards set forth by the military specifications for connectors, guaranteeing compatibility and interchangeability with other MIL-DTL-38999 Series Ⅰ connectors. This standardization simplifies maintenance and replacement in field operations, reducing downtime and improving operational efficiency.

Overall, the MIL-DTL-38999 Series Ⅰ MS27656T23B44SA connector with bayonet coupling, shell size 23, four copper alloy crimp contacts, and a 60 amp current rating is an outstanding choice for applications requiring a reliable, high-performance connector. Its rugged construction, ease of use, and superior electrical characteristics make it a trusted component in critical military and aerospace systems, ensuring dependable operation under even the most challenging conditions.

Features:

• Product Name: MIL-DTL-38999 Series Ⅰ
• Connector Type: Circular
• Gender: Square Flange Receptacle
• Current Rating: 60 A
• Contact Material: Copper Alloy
• Features bayonet coupling for secure and quick mating
• Square flange receptacle design for easy mounting
• Olive Green Cadmium plating for corrosion resistance and durability

Technical Parameters:

Applications:

The KAIDA MIL-DTL-38999 Series Ⅰ connector, model number MS27656T23B44SA, is a highly reliable and robust solution designed for demanding environments. Originating from China, this product is engineered to meet the stringent requirements of military, aerospace, and industrial applications. Featuring a square flange receptacle and bayonet coupling, the connector ensures secure and quick mating, making it ideal for use in situations where rapid assembly and disassembly are essential. The bayonet coupling mechanism provides a positive lock, preventing accidental disconnection under vibration or mechanical stress.

This connector utilizes crimp contacts, which offer excellent electrical performance and mechanical stability. The crimp contact type is preferred in high-vibration environments because it maintains consistent contact pressure and reduces the risk of contact failure. The shell finish of olive green cadmium not only provides corrosion resistance but also meets military specifications for durability and environmental protection.

The MIL-DTL-38999 Series Ⅰ connector operates reliably within a wide temperature range from -55°C to +125°C, making it suitable for extreme environmental conditions. This temperature tolerance allows the connector to be used in aerospace applications where temperature fluctuations are common, as well as in harsh industrial settings such as heavy machinery, transportation, and outdoor installations.

The square flange receptacle design allows for easy panel mounting, providing a secure and stable connection point for electrical systems. The shell size 23 ensures compatibility with a variety of cable diameters and wiring configurations, making it versatile for multiple scenarios. Typical application occasions include military communication systems, avionics, radar equipment, and ground support machinery where dependable signal and power transmission are critical.

In summary, the KAIDA MIL-DTL-38999 Series Ⅰ MS27656T23B44SA connector is an excellent choice for professionals seeking a rugged, reliable, and easy-to-use connector with crimp contacts, bayonet coupling, and a square flange receptacle. Its robust design and operating temperature range make it suitable for aerospace, military, and industrial applications requiring high performance under extreme conditions.

Customization:

KAIDA offers product customization services for the MIL-DTL-38999 Series Ⅰ, model number MS27656T23B44SA. This high-quality circular connector is designed with a shell size of 23 and features crimp contacts made from durable copper alloy. Our customization options include the square flange receptacle configuration, ensuring a secure and reliable connection tailored to your specific needs. Manufactured in China, the MIL-DTL-38999 Series Ⅰ connectors by KAIDA provide excellent performance and durability for demanding applications.

Support and Services:

Product Technical Support and Services for MIL-DTL-38999 Series 1 connectors include comprehensive assistance to ensure optimal performance and reliability. Technical support covers product selection guidance, application engineering, installation instructions, and troubleshooting. Services include connector customization, including shell size and insert arrangements, plating options, and contact styles to meet specific requirements.

We provide detailed product documentation, including datasheets, technical drawings, and compliance certifications. Our experts offer training sessions and seminars to enhance understanding of connector features and best practices. Additionally, repair and refurbishment services are available to extend the life of your connectors.

Our support team is dedicated to helping customers maintain system integrity in demanding environments by delivering prompt and knowledgeable assistance throughout the product lifecycle.

Packing and Shipping:

The MIL-DTL-38999 Series 1 connectors are packaged to ensure protection against damage during handling, storage, and transportation. Each connector is individually packaged in a protective plastic bag or sealed container to prevent contamination from dust, moisture, and other environmental factors. The packaging materials comply with military standards to maintain the integrity of the product throughout its shelf life.

For shipping, the connectors are placed in sturdy, impact-resistant cartons designed to absorb shocks and vibrations. Inner cushioning materials such as foam inserts or bubble wrap are used to secure the connectors in place and prevent movement within the shipping container. The outer packaging is labeled clearly with product information, handling instructions, and relevant military specifications to facilitate proper identification and care during transit.

All packaging and shipping practices adhere to MIL-STD-2073 requirements, ensuring that the MIL-DTL-38999 Series 1 connectors arrive at their destination in optimal condition, ready for immediate use in critical applications.
